Optical Microscope Liab Lens Magnification
Lub hom phiaj liab ntawm lub tshuab ntsuas qhov muag pom pom qhov loj ntawm 4x, daj rau 10x, xiav rau 40x, thiab dawb rau 100x. Ua kom lub qhov muag loj loj los ntawm lub hom phiaj lens magnification kom tau txais tag nrho qhov loj ntawm lub tshuab tsom.
Optical microscope nyob rau hauv kab sab sauv ntawm tus xov tooj "10" thiab "4" hais tias qhov magnification ntawm lub hom phiaj lens rau 10 zaug los yog 4 zaug, qhov magnification tsis yog lub magnification ntawm cheeb tsam, tab sis hais txog lub magnification ntawm qhov ntev los yog dav ntawm daim duab, thiab tag nrho cov microscope magnification yog sib npaug rau cov khoom ntawm lub magnification ntawm lub hom phiaj lens thiab eyepiece. Thiab tag nrho cov magnification ntawm lub tshuab tsom xam yog sib npaug rau cov khoom ntawm lub magnification ntawm lub hom phiaj lens thiab eyepiece, thiab lub magnification ntawm lub hom phiaj lens yog ncaj qha proportional rau nws ntev. Qhov loj dua ntawm lub hom phiaj lens, qhov ntev ntawm lub hom phiaj lens.
Parameters ntawm lub teeb microscope
Kev ua hauj lwm nyob deb ntawm lub hom phiaj lens ntawm lub tshuab ntsuas qhov muag muaj feem xyuam rau qhov ntev ntawm lub hom phiaj lens; qhov ntev ntawm qhov focal ntev ntawm lub hom phiaj lens, qhov qis dua qhov kev nthuav dav thiab ntev dua nws qhov kev ua haujlwm nyob deb. Piv txwv li: Lub hom phiaj 10x lub hom phiaj yog sau npe 10/0.25 thiab 160/0.17, qhov twg 10 yog qhov loj ntawm lub hom phiaj lens. 0.25 yog tus lej aperture; 160 yog qhov ntev ntawm lub thoob (hauv mm); thiab 0.17 yog tus qauv thickness ntawm cov ntaub npog (hauv mm).
Qhov ua haujlwm tau zoo ntawm 10x lub hom phiaj lens yog 6.5mm, thiab qhov ua haujlwm zoo ntawm 40x lub hom phiaj lens yog 0.48mm. Lub luag haujlwm ntawm lub hom phiaj lens yog txhawm rau nthuav dav cov qauv rau thawj zaug, nws yog qhov tseem ceeb tshaj plaws ntawm lub tshuab tsom iav los txiav txim siab qhov kev ua tau zoo ntawm qhov kev daws teeb meem ntawm qhov siab thiab qis.
Thaum lub hom phiaj lo ntsiab muag tau raug daws kom meej meej cov qauv zoo, yog tias tsis yog los ntawm lub ntsej muag rov ua kom loj, tsis mus txog qhov loj ntawm tib neeg lub qhov muag tuaj yeem paub qhov txawv, nws yuav tsis meej; tab sis lub hom phiaj lens tsis tuaj yeem paub qhov txawv ntawm cov qauv zoo, txawm hais tias dhau los ntawm lub qhov muag loj loj loj dua, tab sis kuj tsis tuaj yeem pom meej, yog li lub qhov muag tsuas tuaj yeem ua lub luag haujlwm hauv kev nthuav dav, yuav tsis txhim kho qhov kev daws teeb meem ntawm lub tshuab tsom.
