Digital Infrared Thermometer Non Contact Laser IR Temperature LCD Display Gun Pyrometer Tester Aquarium Temperature Instruments Digital Non contact infrared thermometer Color LCD Digital Non-contact Pyrometer Color LCD
AT380 plus infrared thermometer are safely and quickly used for measuring the temperature of the object's surface without contact. The most basic design consists of a lens to focus the infrared (IR) energy on to a detector, which converts the energy to an electrical signal that can be displayed in units of temperature after being compensated for ambient temperature variation.
Nta
Specification
Temperature range | AT380:-32 degree to 380 degree (-26 to 716 degree F ) AT380 plus :-50C380C(-58F716F) | |
Accuracy(In the condition of 23 degree ±3 degree ) | -32 degree (-26 degree F) to 0 degree (32 degree F) | |
Repeatability | 1 percent of reading or 0.1 degree | |
Response time | 500 mSec, 95 percent response | |
Spectral response | 8-14 um | |
Emissivity | pre{{0}}set 0.95 | |
Ambient operating range | 0 to 40 degree (32 degree Fto 104 degree F) | |
Relative humidity | 10-95 percent RH noncondensing,@up to 30 degree (86 degree F) | |
Storage temperature | -20 to 60 degree (-4 degree Fto 140 degree F) | |
Weight | 130g without battery | |
Dimensions | 132.892.837mm | |
Distance to Spot Size | 12:1 | |
Power Supply | 2 x AAA battery (not inlcude) | |
Package Contents | 1pc AT380 Therometer | |
Quick Start Instruction: | ||
Kauj ruam 1 | Press battery door clip, install battery correctly. Pull the trigger, LCD display reading battery icon. Release the trigger and the reading will hold for 7 seconds. | |
Step 2 | Locating a hot spot: To find a hot spot aim the thermometer outside the area of interest, then scan across with up and down motions until you locate the hot spot.(please turn on the laser for accurate measuring) | |
User's Guide: | ||
Instructions | Compact, rugged and easy to use. Just aim and push the button, read current surface temperature in less than a second. Safely measure surface temperature of hot,hazardous or hard-to-reach objects without contact. | |
How it works | temperature of an object, The optical detector sense the object s emitted energy with different wavelength. It is collected and focus onto a detector. The electronics system translated the information into a temperature reading which is displayed on the unit. | |
Cautions | Infrared thermometer should be protected from the following: | |
Khoom Paub meej
Digital Tsis yog{0}} hu rau Pyrometer Xim LCD
FAQ
1. Koj ua li cas kom paub tseeb tias tus nqi sib tw raws li qhov zoo ib yam?
1). Tus kheej lub Hoobkas sib dhos kab
2). Thawj tes raw khoom nrhiav
3). Ntau tshaj 10 xyoo kev tsim khoom
2. Koj lub tuam txhab ua li cas txog kev tswj kom zoo?
Peb pab pawg QC yuav ua qhov kev soj ntsuam nruj nruj ua ntej xa zaub mov kom paub tseeb tias qhov zoo tshaj plaws.
3. Kuv puas tuaj yeem nug cov qauv ua ntej muab xaj?
Yog lawm, peb txais tos cov qauv txiav txim los kuaj thiab xyuas qhov zoo. Cov qauv sib xyaw ua ke tau txais
4. What's the standard MOQ?
Qauv mus kuaj muaj kev txiav txim lag luam wholesale: 100pieces OEM Order: 1000pieces - 5000pcs
Cim npe nrov: digital tsis- hu rau pyrometer xim lcd, Tuam Tshoj, lwm tus neeg, manufacturers, hoobkas, customized, lag luam wholesale, zoo tshaj plaws, luv nqi, hauv Tshuag, yuav luv nqi
