Dab tsi yog qhov txawv ntawm lub tshuab microscope upright thiab lub tshuab microscope inverted
Metallographic microscope, tseem hu ua cov khoom siv microscope, feem ntau yog siv los saib xyuas cov qauv hlau thiab tuaj yeem muab faib ua upright metallographic microscope thiab inverted metallographic microscope.
Lub upright metallographic microscope dluab raws li ib tug zoo duab thaum lub sij hawm soj ntsuam, uas coj yooj yim heev rau cov neeg siv kev soj ntsuam thiab kev txheeb xyuas. Ntxiv rau kev txheeb xyuas thiab txheeb xyuas cov qauv hlau nrog qhov siab ntawm 20-30mm, nws tau siv ntau dua hauv cov pob tshab, pob tshab, lossis cov khoom tsis pom tseeb vim nws ua raws li tib neeg niaj hnub cwj pwm. Kev soj ntsuam cov khoom loj dua 3 microns tab sis me dua 20 microns, xws li hlau ceramics, hluav taws xob chips, luam tawm circuits, LCD substrates, nyias zaj duab xis, fibers, granular khoom, coatings, thiab lwm yam ntaub ntawv, muaj peev xwm ua tau zoo imaging los ntawm lawv cov qauv nto thiab cov kab ke. Tsis tas li ntawd, cov kev yees duab sab nraud tuaj yeem txuas rau lub vijtsam video thiab lub khoos phis tawj kom yooj yim rau lub sijhawm thiab saib cov duab zoo li qub, khaws cia, kho, luam ntawv, thiab ntau yam software kom tau raws li cov kev xav tau ntawm ntau tus kws tshaj lij metallography, ntsuas, thiab kev sib tham sib qhia. Inverted metallographic microscope siv optical dav hlau imaging txoj kev los txheeb xyuas thiab txheeb xyuas cov microstructure ntawm ntau yam hlau thiab alloys. Nws yog ib qho cuab yeej tseem ceeb rau kev kawm metallography hauv hlau physics thiab tuaj yeem siv dav hauv cov chaw tsim khoom lossis chaw soj nstuam rau kev ua haujlwm zoo, tshuaj xyuas cov khoom siv raw, lossis kev tshawb fawb thiab tshuaj xyuas cov khoom siv metallographic qauv tom qab ua tiav, muab cov txiaj ntsig kev soj ntsuam zoo. Nws yog cov cuab yeej casting hauv mining, metallurgy, manufacturing, thiab mechanical processing industries Cov cuab yeej tseem ceeb rau kev soj ntsuam zoo thiab kev soj ntsuam ntawm smelting thiab kev kho cua sov. Nyob rau hauv xyoo tas los no, vim yog qhov xav tau kev nthuav dav dav dav dav dav dav dav dav siv tshuab los txhawb cov chips hauv kev lag luam microelectronics, metallographic microscopes tau qhia thiab txhim kho tsis tu ncua kom tau raws li cov kev xav tau tshwj xeeb ntawm kev lag luam. Inverted metallographic microscope, vim qhov tseeb tias qhov kev soj ntsuam saum npoo ntawm cov qauv sib txuam nrog qhov chaw ntawm qhov chaw ua haujlwm, thiab lub hom phiaj kev soj ntsuam yog nyob rau hauv qab ntawm lub workbench rau upward soj ntsuam, daim ntawv soj ntsuam no tsis txwv los ntawm qhov siab ntawm tus qauv, thiab yog yooj yim siv. Cov qauv ntsuas yog compact, thiab cov tsos yog zoo nkauj thiab elegant. Lub inverted metallographic microscope puag muaj qhov chaw txhawb nqa loj, qhov chaw qis ntawm lub ntiajteb txawj nqus, thiab ruaj khov thiab txhim khu kev qha. Lub qhov muag thiab qhov chaw txhawb nqa yog tilted ntawm 45 degree, ua rau kev pom zoo.
Ntxiv nrog rau kev xaiv cov qauv kev teeb tsa, lub inverted metallographic microscope muaj cov duab tso zis ncaj qha los ntawm kev txhim kho thev naus laus zis, uas tuaj yeem txuas tau yooj yim hauv khoos phis tawj thiab siv software rau kev ua haujlwm ntse raws li cov txheej txheem yuav tsum tau ua. Cias muab, tso tus qauv upright hauv qab no thiab tus qauv inverted saum toj no. Lub hom phiaj upright yog tig downwards, thiab lub hom phiaj inverted yog tig upwards. Qhov ntawd yog hais tias, lub lens inverted yog nyob rau hauv theem, thiab qhov kev sim thaiv yog muab tso rau pem hauv ntej ntawm theem. Lub sijhawm no, lub lens poob qis, thiab qhov ntsuas ntsuas tau rov qab rau saum. Lub lens soj ntsuam qhov chaw kuaj ntawm hauv qab mus rau saum.
Lub lens upright yog muab tso rau ntawm theem, nrog rau qhov kev sim thaiv lub ntsej muag upwards. Lub sijhawm no, lub lens yog nyob rau sab saum toj, qhov ntsuas ntsuas yog upright, thiab lub lens saib qhov ntsuas qhov saum npoo ntawm sab saum toj mus rau hauv qab.
Tom qab xaiv ib yam ntawm lub tshuab tsom xam raws li cov qauv, txiav txim siab seb puas yuav xaiv lub tshuab microscope upright lossis lub tshuab ntsuas inverted tuaj yeem xa mus rau cov ntsiab lus saum toj no. Nyob rau tib lub sijhawm, koj kuj yuav tsum xav txog koj qhov kev npaj ua qauv uas twb muaj lawm, vim tias lub tshuab ntsuas hluav taws xob ncaj ncees muaj qhov xav tau ntau dua rau kev npaj ua qauv, thaum lub tshuab ntsuas hluav taws xob muaj qhov qis dua.
