Yuav ua li cas ntsuas lub cev muaj zog nrog multimeter
Qhov zoo lossis qhov tsis zoo ntawm lub cev muaj zog nrog lub multimeter tsuas tuaj yeem ua qhov kev txiav txim ua ntej, uas yog, siv lub multimeter los kuaj xyuas lub cev muaj zog coil. Tab sis txawm hais tias lub cev muaj zog muaj qhov tsis zoo hauv av rwb thaiv tsev thiab theem-rau-theem rwb thaiv tsev tseem yuav tsum tau siv cov hluav taws xob sib txuas hluav taws xob hluav taws xob hluav taws xob tuav lub rooj txiav txim.
Ua ntej ntawm tag nrho cov, ib-theem lub cev muaj zog: siv ib tug multimeter los xyuas qhov yuav tsum tau disengage lub capacitor mus xyuas, uas yog hais tias, disengage lub capacitor mus xyuas lub ib-theem lub cev muaj zog lub ntsiab winding thiab lub thib ob winding tsis kam, feem ntau yog cov tsis kam. lub ntsiab winding kuj yog me me, qhov thib ob winding kuj yog qhov loj, feem ntau rau peb lub terminals, koj tuaj yeem ntsuas tus nqi tsis kam, nyob rau hauv ib txwm muaj, koj tuaj yeem tau txais peb qhov kev tiv thaiv tus nqi ntawm qhov loj tshaj plaws ntawm ob qho tib si thiab sum ntawm tus nqi kuj. Capacitors yuav tsum tau kuaj xyuas nyias (capacitor yuav tsum tau tso tawm ua ntej), lub multimeter yuav ntaus cov ntaub ntawv capacitance tuaj yeem ntsuas ncaj qha.
Peb-theem lub cev muaj zog: Yog hais tias nws yog ib tug me me peb-theem lub cev muaj zog nrog lub hnub qub kev twb kev txuas, koj muaj peev xwm tshem tawm lub luv luv txuas ua ntej, thiab siv lub multimeter los ntsuas qhov tsis kam ntawm peb coils feem, tus nqi kuj feem ntau tsis loj heev, thiab qhov sib txawv yuav tsis loj heev, thiab nruab nrab ntawm cov theem thiab mus rau hauv av nrog lub multimeter yuav tsum tau txiav. Yog tias tus nqi tiv thaiv tsis ruaj khov thaum kuaj xyuas nrog lub multimeter, nws yog qhov zoo dua los siv lub rooj sib txuas rwb thaiv tsev kom paub meej.
High-voltage motor: kev soj ntsuam ntawm high-voltage lub cev muaj zog yuav tsum tau kev cob qhia cov cuab yeej los xyuas, siv ib tug multimeter los txiav txim qhov yooj yim kev huam yuaj.
Lub cev muaj zog zoo lossis qhov tsis zoo ua ntej kev txiav txim siab ntsuas yog ib qho tseem ceeb, qee zaum muaj qhov tsis ua haujlwm tam sim ntawd mus rau dismantle lub cev muaj zog, yog li qhov kev txiav txim ua ntej kuj yog ib qho yooj yim mus nrhiav cov crux sai.
Lub cev muaj zog zoo lossis kev txiav txim siab phem
Hnov cov ntxhiab tsw ntawm qhov chaw, yog tias koj hnov qhov tsw ntawm qhov kub hnyiab yog qhov yuav raug hlawv tawm ntawm lub cev muaj zog. Peb-theem lub cev muaj zog peb-theem hauv av rwb thaiv tsev ntsuas muaj kev nkag tau tshwm sim, tej zaum yuav nyob rau hauv qhov kev tshawb pom taw tes rau lub cev muaj zog ntawm lub cable luv luv Circuit Court. Nws tseem muaj peev xwm hais tias ib theem davhlau ya nyob twg ntawm lub cev muaj zog terminal lub thawv yog nyob rau hauv kev sib cuag nrog lub plhaub. Nws kuj tseem ua tau tias cov rwb thaiv tsev sab hauv ntawm lub cev muaj zog yog nyob rau hauv kev sib cuag nrog lub plhaub.
Cov kab hluav taws xob ntawm lub cev muaj zog tuaj yeem muaj luv luv Circuit Court kuj tseem muaj qhov luv luv ntawm peb-theem terminals nrog rau cov kab hluav taws xob luv luv hauv lub cev muaj zog ntawm cov theem. Kev ntsuas ntawm lub cev muaj zog peb-theem hluav taws xob rwb thaiv tsev ntawm peb theem kuj tseem tsis kawg, yuav raug ntsuas mus rau qhov taw tes rau lub cev muaj zog ntawm lub cable tawg lossis lub cev muaj zog peb-theem terminals ntawm lub shedding, los yog lub cev muaj zog sab hauv winding raug hlawv. raws li lub cev muaj zog qhov nruab nrab daim tawg.
Ntsuas qhov kev tiv thaiv ntawm peb theem ntawm peb-theem lub cev muaj zog, xws li ab, ac, bc, yog tias qhov ntsuas kev tiv thaiv ntawm lawv loj, muaj peb-theem imbalance nyob rau hauv lub cev muaj zog, nws yuav zoo li lub cev muaj zog. tawm sab hauv.
Kev ntsuas ntawm lub cev nruab nrab ntawm lub cev thiab lub plhaub lub cev muaj zog, xoom, tom qab ntawd yuav muaj tsawg kawg yog ib theem ntawm cov txheej txheem rwb thaiv tsev kub hnyiab los ntawm kev sib cuag nrog lub plhaub lub cev muaj zog los tsim ib qho kev luv luv hauv av. Tshem tawm qhov nruab nrab ntawm lub cev muaj zog los ntsuas cov theem ntawm lub cev muaj zog thiab lwm qhov kawg ntawm lub cev muaj zog sib haum rau qhov nruab nrab, yog tias qhov tshwm sim yog xoom, lub cev muaj zog yuav raug hlawv hauv qhov uas ua rau muaj kev cuam tshuam.
Ntau qhov kev ua tsis tiav yog qhov tsis tuaj yeem xav txog, cov neeg ua haujlwm saib xyuas tsuas tuaj yeem txiav txim siab ua ntej, cov teeb meem tshwj xeeb yuav tsum tau txheeb xyuas tshwj xeeb, nws yog qhov tsis muaj qee cov lus.
Nrog ib tug multimeter los ntsuas lub cev muaj zog rwb thaiv tsev kuv tus kheej xav tias nws yog ib qho nyuaj rau ua tiav cov kev xav tau. Vim hais tias qhov ntau ntawm ohm ntawm lub multimeter me dhau, qhov siab tshaj plaws yog 10KΩ, thiab peb-theem lossis ib-theem lub cev muaj zog hluav taws xob theem rwb thaiv tsev, rwb thaiv tsev rau hauv av tsis tsawg dua qhov tsawg kawg nkaus ntawm {{ 7}}.5 megohm (MΩ) 10kΩ uas yog, 1OOOOO Ohm Ω thaum lub 0.50 megohm (Ω) yog 5 txhiab lab Ohm (Ω,) saib qhov ntsuas ntawm lub cev muaj zog yam tsis muaj lub rooj rwb thaiv tsev yog tiag tiag tawm.
Kev ntsuas ntawm 380 volts lossis ib-theem lub cev muaj zog rwb thaiv tsev yog qhov kev xaiv zoo tshaj plaws ntawm 500 volts (v) co lub rooj, txhawm rau ntsuas peb theem (A, B, C) theem-rau-theem rwb thaiv tsev thiab ntug hauv av .
Thaum tsis muaj pob zeb ntsuas ntsuas, koj tuaj yeem siv multimeter los ntsuas ntsuas, ohm 1 OK block yog mus txog infinity tsis tuaj yeem suav tias lub tshuab hluav taws xob tsim nyog. Lub sijhawm no koj tuaj yeem tig lub zog los sim lub tshuab, kaw lub rooj vag kom kaw nrawm nrawm nrawm, kaw lub rooj vag saib qhov loj ntawm lub tshuab hluav taws xob ib leeg, mloog lub suab khiav yog qhov qub, tsis muaj kev vibration. , yog hais tias lawv ib txwm nrog ib tug xeem cwj mem los ntsuas lub plhaub seb lub to, txhua yam yog zoo li qub ua ntej muab tso rau hauv lub lag luam.
