Xaiv lub tswv yim qauv thiab specifications ntse
Nyob rau hauv cov hlau lead-dawb soldering, cov lus qhia hlau soldering tsis yog universal. Kev xaiv tus qauv raug thiab cov lus qhia tshwj xeeb ntawm cov taub hau hlau tuaj yeem txhim kho kev ua haujlwm. Cov nyhuv vuam kuj tuaj yeem txhim kho! Cov hauv qab no yog qhov ntau ntawm kev siv pom zoo los ntawm Gerun soldering tip chaw tsim tshuaj paus rau ntau yam qauv thiab specifications!
B, LB hom (conical hom)
Nta: B-hom soldering hlau taub tsis muaj kev taw qhia, thiab tag nrho pem hauv ntej kawg ntawm lub taub hau tuaj yeem welded.
Scope ntawm daim ntawv thov: Haum rau kev siv dav dav, tsis hais txog qhov loj ntawm cov pob qij txha, B-hom soldering hlau cov lus qhia kuj siv tau.
K hom ( riam hom)
Nta: Cov hniav zoo li yog siv rau vuam, thiab nws tuaj yeem siv rau ntsug lossis rub-vuam vuam. Nws yog ib tug multi-purpose soldering hlau taub.
Daim ntawv thov: Haum rau SOJ, PLCC, SOP, QFP, fais fab mov, cov khoom siv hauv av, kho tin choj, connectors, thiab lwm yam.
Hom I (pointed)
Nta: Lub hau ntawm lub taub hau ntawm lub taub hau yog zoo.
Scope ntawm daim ntawv thov: Tsim nyog rau kev vuam zoo lossis thaum qhov chaw vuam me me. Nws kuj tseem tuaj yeem kho cov choj tin uas tsim thaum vuam chips.
D. LD hom (paj hom / tiaj tus nozzle hom)
Flat hom muaj xws li 0.8D, 1.2D, 1.6D, 2.4D, 3.2D, 4.2D, thiab lwm yam.
Nta: Siv lub nozzle rau vuam.
Scope ntawm daim ntawv thov: haum rau vuam uas yuav tsum tau ib tug loj npaum li cas ntawm tin, xws li ib tug vuam ib puag ncig nrog ib tug loj vuam cheeb tsam, tuab terminals, thiab loj soldering pads.
C, CF hom (horseshoe hom / beveled cylindrical hom)
Horseshoe hom muaj xws li {{0}}.5C, 0.8C, 1C, 2C, 3C, 4C, thiab lwm yam.
Nta: Siv lub beveled ib feem ntawm lub hauv ntej kawg ntawm lub soldering hlau ntsis rau vuam, haum rau vuam uas yuav tsum tau ib tug loj npaum li cas ntawm tin.
Daim ntawv thov ntau yam: Daim ntawv thov ntau yam ntawm C-hom soldering hlau taub yog zoo ib yam li D-hom soldering hlau taub, xws li loj vuam cheeb tsam, tuab terminals thiab loj soldering pads.
0.5C, 1C, 1.5CF thiab lwm cov lus qhia hlau soldering yog zoo heev, haum rau soldering me me Cheebtsam, los yog kho tin choj, tin pillars, thiab lwm yam. generated thaum lub sij hawm deg soldering. Yog hais tias tsuas yog ib qho me me ntawm cov khoom siv rau vuam, nws yog qhov tsim nyog siv CF hom soldering hlau taub nrog tin plating nkaus xwb ntawm lub bevel.
2C thiab 3C hom soldering hlau tswv yim yog tsim rau soldering Cheebtsam xws li resistors thiab diodes. SOP thiab QFP nrog cov hniav loj dua tuaj yeem siv tau.
4C, haum rau tuab terminals thiab grounding ntawm Circuit Court boards. Vuam cov xwm txheej uas yuav tsum tau muaj cua sov ntau, xws li cov khoom siv hluav taws xob.
Hom H (khoov qhov ntswg hom)
Nta: Lub tin plating txheej yog nyob rau hauv qab ntawm lub soldering hlau taub.
Daim ntawv thov: Haum rau rub vuam SOP thiab QFP nrog cov hniav loj
